Automatic labelling machines for self-adhesive labels are designed for labelling bottles, flasks, jars and other cylindrical and shaped containers.

The self-adhesive labeling series is available in various models with 3, 6, 10, or 12 plates arranged on a central carousel.
They can also be equipped with one to five labeling units to meet all application and production speed requirements.

A further possibility for customization is given by the various options available (touch-screen programming controller, hot printer, bottle accumulation tables)

All labelling units are equipped with a dedicated electronic board and can be equipped with special sensors for applying transparent labels.

TECHNICAL DATA SHEET
‘CE’ safety guards with wide stainless steel bands
Central carousel with 3 – 6 – 10 – 12 bottle holders
Plate movement by double profile cams in oil bath
Bottle-holding heads with pneumatic locking system
Height adjustment of the upper carousel
Labelling stations driven by stepper motors, for maximum application precision
Electronic board for label start signal in presence of bottle
Height and inclination adjustment with handwheels and metric reference scales
Stations mounted on 3-shaft support, for maximum solidity and absence of vibrations during work
Double shock absorber arm for label film
Reel rewinder with friction system
Electronic speed variation with inverter
Electronic synchronization of station speed with carousel speed
Emergency machine stop devices on the auger, starwheels, and central shaft
Machine constructed entirely of stainless steel, with scratch-resistant and corrosion-resistant painted aluminum parts.
